UL 94 CERTIFIED FOAM SEALS

Together with our customers and suppliers, we always find the right solution when seals must be used in accordance with fire safety standards. In addition to meeting fire safety requirements, the suitability of the material for dust and air tightness is also important when selecting materials. This material table is only a small selection of materials from a larger range.

Learn more
about ISOWA

OUR FOAMS FOR WHITE APPLIANCES

IS 210400
Cellular rubber
EPDM - CR

show details

Details

CELL STRUCTURE
closed
THICKNESS
2 - 50 mm
COLOR
black
TEMPERATURE (°C)
-40 / +100 °C
(short-term +115 °C)
FULFILLED STANDARDS
Fire behavior according to UL 94 / HBF from 5 mm
ISO 846 - micorobular inertness
SPECIAL PROPERTIES
Good resistance to weathering and ozone
AREAS OF APPLICATION
gasket

IS 262915
Polyethylene

show details

Details

CELL STRUCTURE
closed
THICKNESS
2 - 45 mm
COLOR
white
black
TEMPERATURE (°C)
-70 / +100 °C
FULFILLED STANDARDS
Fire behavior according to UL 94 HF 1 and DIN 4102 B1
SPECIAL PROPERTIES
Good thermal energy value of 0.0351 W/mK, free from CFC-containing foaming agents.
AREAS OF APPLICATION
Sealing, insulation

IS 266904
Polyolefin
Elafit

show details

Details

CELL STRUCTURE
closed
THICKNESS
3 - 8 mm
COLOR
anthracite
TEMPERATURE (°C)
+90 °C
FULFILLED STANDARDS
Fire behavior according to
DIN 4102 B2 and
EN 13501-1 class E.
SPECIAL PROPERTIES
very soft, different compression hardnesses available
AREAS OF APPLICATION
Sealing, padding

IS 260300 plus
polyethylene with
aluminized foil

show details

Details

CELL STRUCTURE
closed
THICKNESS
2 - 8 mm
COLOR
anthracite
aluminum
TEMPERATURE (°C)
-80 / +100 °C
FULFILLED STANDARDS
ISO 846 - micorobular inertness
SPECIAL PROPERTIES
better heat radiation due to additional film
AREAS OF APPLICATION
Sealing, insulation

IS 321102
Polyurethane

show details

Details

CELL STRUCTURE
open
THICKNESS
3 - 24 mm
COLOR
anthracite
FULFILLED STANDARDS
Fire behavior according to
FMVSS 302
SPECIAL PROPERTIES
very soft, permeable to air
AREAS OF APPLICATION
acute applications, soft positioning, padding

IS 272305
Filter foam
PPI 30

show details

Details

CELL STRUCTURE
open
THICKNESS
3 - 50 mm
COLOR
anthracite
SPECIAL PROPERTIES
open mesh structure enables high dust load
AREAS OF APPLICATION
Coarse filters in ventilation and air conditioning systems

IS 320340
PUR elastomer

show details

Details

CELL STRUCTURE
mixed
THICKNESS
2 - 25 mm
COLOR
green
TEMPERATURE (°C)
-30 / +70 °C
FULFILLED STANDARDS
Fire behavior according to
DIN 13501 class E
SPECIAL PROPERTIES
Excellent values for vibration damping and structure-borne sound decoupling
AREAS OF APPLICATION
Bearing of components, sound decoupling

ANSWERS ABOUT CERTIFIED FOAM SEALS

OUR PRODUCTS

Punched parts

Seals for add-on parts.

Vibration protection

To reduce vibrations in fans.

Acoustic cap

Isolation from disturbing noises.

The specialist

To reduce vibrations in fans.

PE profiles

Individual thermal separation of components.

Cable guides

Simple installation and secure hold of the cable.

Cable bushings

Individual solutions for partition walls.

Non-woven embossed parts

Proven and effective noise reduction.
